CC1110Fx / CC1111Fx
T2CTL (0x9E) - Timer 2 Control
Bit
Field Name
Reset
R/W
Description
7
0
R/W
0
Reserved
6
TEX
0
R/W
0
This bit is set to 1 when the timer count reaches 0x00. Writing a 1 to this bit has no
effect
5
4
0
0
R/W
R/W
Reserved. Always set to 0.
Timer 2 Interrupt enable
INT
0
1
Interrupt disable
Interrupt enable
3
2
0
0
R/W
R/W
Reserved. Always set to 0
Tick generator mode
TIG
0
Tick generator is running when T2CT not equal to 0x00. The tick generator
will always start running form its null state.
1
Tick generator is in free-running mode. If it is not already running it will start
from its null state when this bit is set to 1
1:0
TIP[1:0]
00
R/W
This value is used to calculate the timer 2 interval / time slot, T
T = T2PR ∙ Val(T2CTL.TIP)/ timer tick speed,
00
01
10
11
64
128
256
1024
T2CT (0x9C) - Timer 2 Count
Bit
Field Name
Reset
R/W
Description
7:0
CNT[7:0]
0x00
R/W
Timer count. Contents of 8-bit counter.
T2PR (0x9D) - Timer 2 Prescaler
Bit
Field Name
Reset
R/W
Description
7:0
PR[7:0]
0x00
R/W
Timer prescaler multiplier. 0x00 is interpreted as 256
SWRS033H
Page 125 of 246
