5.6.2.2.2.7 High-Speed Bypass Capacitors
High-speed (HS) bypass capacitors are critical for proper DDR2 interface operation. It is particularly
important to minimize the parasitic series inductance of the HS bypass capacitors, AM335x device DDR2
power, and AM335x device DDR2 ground connections. Table 5-49 contains the specification for the HS
bypass capacitors as well as for the power connections on the PCB.
Table 5-49. High-Speed Bypass Capacitors
NO.
1
PARAMETER
MIN
MAX
UNIT
HS bypass capacitor package size(1)
0402 10 mils
2
Distance from HS bypass capacitor to device being bypassed
Number of connection vias for each HS bypass capacitor(2)
250
30
mils
Vias
mils
3
2
1
1
4
Trace length from bypass capacitor contact to connection via
5
Number of connection vias for each AM335x VDDS_DDR and VSS terminal
Trace length from AM335x VDDS_DDR and VSS terminal to connection via
Number of connection vias for each DDR2 device power and ground terminal
Trace length from DDR2 device power and ground terminal to connection via
AM335x VDDS_DDR HS bypass capacitor count(3)
Vias
mils
6
35
7
Vias
mils
8
35
9
10
0.6
8
Devices
μF
10 AM335x VDDS_DDR HS bypass capacitor total capacitance
11 DDR2 device HS bypass capacitor count(3)(4)
12 DDR2 device HS bypass capacitor total capacitance(4)
Devices
μF
0.4
(1) LxW, 10-mil units; for example, a 0402 is a 40x20-mil surface-mount capacitor.
(2) An additional HS bypass capacitor can share the connection vias only if it is mounted on the opposite side of the board.
(3) These devices should be placed as close as possible to the device being bypassed.
(4) Per DDR2 device.
5.6.2.2.2.8 Net Classes
Table 5-50 lists the clock net classes for the DDR2 interface. Table 5-51 lists the signal net classes, and
associated clock net classes, for the signals in the DDR2 interface. These net classes are used for the
termination and routing rules that follow.
Table 5-50. Clock Net Class Definitions
CLOCK NET CLASS AM335x PIN NAMES
CK
DDR_CK and DDR_CKn
DQS0
DQS1
DDR_DQS0 and DDR_DQSn0
DDR_DQS1 and DDR_DQSn1
Table 5-51. Signal Net Class Definitions
ASSOCIATED CLOCK
SIGNAL NET CLASS
AM335x PIN NAMES
NET CLASS
ADDR_CTRL
CK
DDR_BA[2:0], DDR_A[15:0], DDR_CSn0, DDR_CASn, DDR_RASn,
DDR_WEn, DDR_CKE, DDR_ODT
DQ0
DQ1
DQS0
DQS1
DDR_D[7:0], DDR_DQM0
DDR_D[15:8], DDR_DQM1
