AM3359, AM3358, AM3357
AM3356, AM3354, AM3352
www.ti.com
SPRS717F OCTOBER 2011REVISED APRIL 2013
5.6.2.2.2.2 Compatible JEDEC DDR2 Devices
Table 5-44 shows the parameters of the JEDEC DDR2 devices that are compatible with this interface.
Generally, the DDR2 interface is compatible with x16 or x8 DDR2-533 speed grade DDR2 devices.
Table 5-44. Compatible JEDEC DDR2 Devices (Per Interface)(1)
NO.
1
PARAMETER
JEDEC DDR2 device speed grade(2)
MIN
MAX
UNIT
DDR2-533
2
JEDEC DDR2 device bit width
JEDEC DDR2 device count
x8
1
x16
2
Bits
3
Devices
4
JEDEC DDR2 device terminal count(3)
60
84 Terminals
(1) If the DDR2 interface is operated with a clock frequency less than 266 MHz, lower-speed grade DDR2 devices may be used if the
minimum clock period specified for the DDR2 device is less than or equal to the minimum clock period selected for the AM335x DDR2
interface.
(2) Higher DDR2 speed grades are supported due to inherent JEDEC DDR2 backwards compatibility.
(3) 92-terminal devices are also supported for legacy reasons. New designs will migrate to 84-terminal DDR2 devices. Electrically, the 92-
and 84-terminal DDR2 devices are the same.
5.6.2.2.2.3 PCB Stackup
The minimum stackup required for routing the AM335x device is a four-layer stackup as shown in Table 5-
45. Additional layers may be added to the PCB stackup to accommodate other circuitry, enhance signal
integrity and electromagnetic interference performance, or to reduce the size of the PCB footprint.
Table 5-45. Minimum PCB Stackup(1)
LAYER
TYPE
Signal
Plane
Plane
Signal
DESCRIPTION
Top signal routing
Ground
1
2
3
4
Split Power Plane
Bottom signal routing
(1) All signals that have critical signal integrity requirements should be routed first on layer 1. It may not be possible to route all of these
signals on layer 1 which requires some to be routed on layer 4. When this is done, the signal routes on layer 4 should not cross splits in
the power plane.
Copyright © 2011–2013, Texas Instruments Incorporated
Peripheral Information and Timings
161
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
