8.6.18 CH1_GCAL_MSB Register (Address = 11h) [reset = 8000h]
The CH1_GCAL_MSB register is shown in 图8-43 and described in 表8-31.
Return to the Summary Table.
图8-43. CH1_GCAL_MSB Register
15
14
13
12
11
10
9
1
8
0
GCAL1_MSB[15:8]
R/W-10000000b
7
6
5
4
3
2
GCAL1_MSB[7:0]
R/W-00000000b
表8-31. CH1_GCAL_MSB Register Field Descriptions
Bit
15:0
Field
GCAL1_MSB[15:0]
Type
Reset
Description
R/W
1000000000
000000b
Channel 1 gain calibration register bits [23:8]
8.6.19 CH1_GCAL_LSB Register (Address = 12h) [reset = 0000h]
The CH1_GCAL_LSB register is shown in 图8-44 and described in 表8-32.
Return to the Summary Table.
图8-44. CH1_GCAL_LSB Register
15
14
13
12
11
10
2
9
1
8
0
GCAL1_LSB[7:0]
R/W-00000000b
7
6
5
4
3
RESERVED
R-00000000b
表8-32. CH1_GCAL_LSB Register Field Descriptions
Bit
Field
Type
Reset
Description
15:8
7:0
GCAL1_LSB[7:0]
RESERVED
R/W
00000000b
Channel 1 gain calibration register bits [7:0]
R
00000000b
Reserved
Always reads 00000000b
