8.6.21 CH2_OCAL_MSB Register (Address = 14h) [reset = 0000h]
The CH2_OCAL_MSB register is shown in 图8-46 and described in 表8-34.
Return to the Summary Table.
图8-46. CH2_OCAL_MSB Register
15
14
13
12
11
10
9
1
8
0
OCAL2_MSB[15:8]
R/W-00000000b
7
6
5
4
3
2
OCAL2_MSB[7:0]
R/W-00000000b
表8-34. CH2_OCAL_MSB Register Field Descriptions
Bit
15:0
Field
OCAL2_MSB[15:0]
Type
Reset
Description
R/W
00000000
00000000b
Channel 2 offset calibration register bits [23:8]
8.6.22 CH2_OCAL_LSB Register (Address = 15h) [reset = 0000h]
The CH2_OCAL_LSB register is shown in 图8-47 and described in 表8-35.
Return to the Summary Table.
图8-47. CH2_OCAL_LSB Register
15
14
13
12
11
10
2
9
1
8
0
OCAL2_LSB[7:0]
R/W-00000000b
7
6
5
4
3
RESERVED
R-00000000b
表8-35. CH2_OCAL_LSB Register Field Descriptions
Bit
Field
Type
Reset
Description
15:8
7:0
OCAL2_LSB[7:0]
RESERVED
R/W
00000000b
Channel 2 offset calibration register bits [7:0]
R
00000000b
Reserved
Always reads 00000000b
