8.6.11 CH0_OCAL_MSB Register (Address = Ah) [reset = 0000h]
The CH0_OCAL_MSB register is shown in 图8-36 and described in 表8-24.
Return to the Summary Table.
图8-36. CH0_OCAL_MSB Register
15
14
13
12
11
10
9
1
8
0
OCAL0_MSB[15:8]
R/W-00000000b
7
6
5
4
3
2
OCAL0_MSB[7:0]
R/W-00000000b
表8-24. CH0_OCAL_MSB Register Field Descriptions
Bit
15:0
Field
OCAL0_MSB[15:0]
Type
Reset
Description
R/W
00000000
00000000b
Channel 0 offset calibration register bits [23:8]
8.6.12 CH0_OCAL_LSB Register (Address = Bh) [reset = 0000h]
The CH0_OCAL_LSB register is shown in 图8-37 and described in 表8-25.
Return to the Summary Table.
图8-37. CH0_OCAL_LSB Register
15
14
13
12
11
10
2
9
1
8
0
OCAL0_LSB[7:0]
R/W-00000000b
7
6
5
4
3
RESERVED
R-00000000b
表8-25. CH0_OCAL_LSB Register Field Descriptions
Bit
Field
Type
Reset
Description
15:8
7:0
OCAL0_LSB[7:0]
RESERVED
R/W
00000000b
Channel 0 offset calibration register bits [7:0]
R
00000000b
Reserved
Always reads 00000000b
