8.6.16 CH1_OCAL_MSB Register (Address = Fh) [reset = 0000h]
The CH1_OCAL_MSB register is shown in 图8-41 and described in 表8-29.
Return to the Summary Table.
图8-41. CH1_OCAL_MSB Register
15
14
13
12
11
10
9
1
8
0
OCAL1_MSB[15:8]
R/W-00000000b
7
6
5
4
3
2
OCAL1_MSB[7:0]
R/W-00000000b
表8-29. CH1_OCAL_MSB Register Field Descriptions
Bit
15:0
Field
OCAL1_MSB[15:0]
Type
Reset
Description
R/W
00000000
00000000b
Channel 1 offset calibration register bits [23:8]
8.6.17 CH1_OCAL_LSB Register (Address = 10h) [reset = 0000h]
The CH1_OCAL_LSB register is shown in 图8-42 and described in 表8-30.
Return to the Summary Table.
图8-42. CH1_OCAL_LSB Register
15
14
13
12
11
10
2
9
1
8
0
OCAL1_LSB[7:0]
R/W-00000000b
7
6
5
4
3
RESERVED
R-00000000b
表8-30. CH1_OCAL_LSB Register Field Descriptions
Bit
Field
Type
Reset
Description
15:8
7:0
OCAL1_LSB[7:0]
RESERVED
R/W
00000000b
Channel 1 offset calibration register bits [7:0]
R
00000000b
Reserved
Always reads 00000000b
