8.6.20 CH2_CFG Register (Address = 13h) [reset = 0000h]
The CH2_CFG register is shown in 图8-45 and described in 表8-33.
Return to the Summary Table.
图8-45. CH2_CFG Register
15
14
13
12
11
10
9
1
8
0
PHASE2[9:2]
R/W-0000000000b
7
6
5
4
3
2
PHASE2[2:0]
R/W-0000000000b
RESERVED
R-000b
DCBLK2_DIS0
R/W-0b
MUX2[1:0]
R/W-00b
表8-33. CH2_CFG Register Field Descriptions
Bit
Field
Type
Reset
Description
15:6
PHASE2[9:0]
R/W
0000000000
b
Channel 2 phase delay
Phase delay in modulator clock cycles provided in two's complement
format. See 表8-5 for details.
5:3
2
RESERVED
R
000b
0b
Reserved
Always reads 000b
DCBLK2_DIS0
R/W
DC block filter for channel 2 disable
0b = Controlled by DCBLOCK[3:0] (default)
1b = Disabled for this channel
1:0
MUX2[1:0]
R/W
00b
Channel 2 input selection
00b = AIN2P and AIN2N (default)
01b = ADC inputs shorted
10b = Positive DC test signal
11b = Negative DC test signal
