DIGITAL DECIMATION FILTER
The digital filter receives the modulator output and decimates the data stream. By adjusting the amount of
filtering, tradeoffs can be made between resolution and data rate: filter more for higher resolution, filter less for
higher data rates. Higher data rates are typically used in EEG applications for ac lead-off detection.
The digital filter on each channel consists of a third-order sinc filter. The sinc filter decimation ratio can be
adjusted by the DR bits in the CONFIG1 register (see the Register Map section for details). This setting is a
global setting that affects all channels and, therefore, all channels operate at the same data rate in a device.
Sinc Filter Stage (sinx / x)
The sinc filter is a variable decimation rate, third-order, low-pass filter. Data are supplied to this section of the
filter from the modulator at the rate of fMOD. The sinc filter attenuates the modulator high-frequency noise, then
decimates the data stream into parallel data. The decimation rate affects the overall converter data rate.
Equation 4 shows the scaled Z-domain transfer function of the sinc filter.
3
1 - Z- N
½H(z)½ =
1 - Z- 1
(4)
The frequency domain transfer function of the sinc filter is shown in Equation 5.
3
Npf
sin
fMOD
H(f)½ =
pf
N ´ sin
fMOD
where:
N = decimation ratio
(5)
