Both register have an X-Bus Access Request bit and an X-Bus Access Grant bit. Table 70 offers a summary of how
each bus will be granted the X-Bus.
Request Access to X-Bus
When either bus wants to access the X-Bus, they must set Bit [0] of their respective arbitration register to ‘1’.
Requests are granted on a first-come first-serve basis. Once a request is granted, no other request may be granted
until the bus that is holding the X-Bus resets its request bit to ‘0’.
Note: The request bit should remain high for the duration of the entire transaction. If removed prematurely and if the
other bus is making a request, the transaction will be terminated and the new request will be granted.
To ensure the SMBus can always gain control of the X-Bus, the SMB_ARB Arbitration register has a Master Request
bit. If the LPC interface is unable to clear its request bit, the SMBus can assert a request by placing a ‘1’ on bit[2] of
the SMB_ARB Arbitration register.
X-Bus Access Granted
Each arbitration register has an X-Bus Access Grant bit, which is set by hardware only. Each bus must monitor their
own grant bit to determine when they have been granted access to the X-Bus. Each interface should verify that
access has been granted to them before initiating any I/O transactions.
Note: The LPC Bus is granted access to the X-Bus by default at boot-up. The LPC interface should not clear the
request bit until boot-up is complete.
Table 70 − SMBus2/LPC Arbitration Summary
PAST STATE
OUTPUTS
PRESENT STATE
INPUTS
OUTPUTS
SMB_GNT
LPC_GNT
LPC_REQ
SMB_REQ
SMB_MRQ
SMB_GNT
LPC_GNT
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
1
1
1
1
0
0
0
0
0
0
0
0
1
0
0
0
0
0
0
1
0
0
0
0
1
0
1
1
0
1
0
0
1
1
0
1
↑
1
1
0
↑
Note 1
Note 1
↑
na
0
↑
na
0
1
0
1
0
1
1
0
1
0
1
0
0
0
1
1
0
1
↑
na
na
Note: The ↑ represents a transition from a ‘0’ to a ‘1'.
Note: na means not applicable (i.e. Don’t Care).
Note 1: If LPC_REQ and SMB_REQ “transition” to a ‘1’ at the same time, arbitration logic produces either
LPC_GNT=’1’ or SMB_GNT=’1’ based on a first-come first-serve basis. For the case when they transition to a ‘1’ at
the same time, circuitry is implented to prevent oscillation.
