C8051F52x-53x
SFR Definition 14.7. P0MAT: Port0 Match
R/W
Bit7
R/W
Bit6
R/W
Bit5
R/W
Bit4
R/W
Bit3
R/W
Bit2
R/W
Bit1
R/W
Reset Value
11111111
Bit0
SFR Address:
0xD7
Bits7–0: P0MAT[7:0]: Port0 Match Value.
These bits control the value that unmasked P0 Port pins are compared against. A Port
Match event is generated if (P0 & P0MASK) does not equal (P0MAT & P0MASK).
SFR Definition 14.8. P0MASK: Port0 Mask
R/W
Bit7
R/W
Bit6
R/W
Bit5
R/W
Bit4
R/W
Bit3
R/W
Bit2
R/W
Bit1
R/W
Reset Value
00000000
Bit0
SFR Address:
0xC7
Bits7–0: P0MASK[7:0]: Port0 Mask Value.
These bits select which Port pins will be compared to the value stored in P0MAT.
0: Corresponding P0.n pin is ignored and cannot cause a Port Match event.
1: Corresponding P0.n pin is compared to the corresponding bit in P0MAT.
128
Rev. 0.3
