C8051F52x-53x
SFR Definition 14.11. P1MDOUT: Port1 Output Mode
R/W
Bit7
R/W
Bit6
R/W
Bit5
R/W
Bit4
R/W
Bit3
R/W
Bit2
R/W
Bit1
R/W
Reset Value
00000000
Bit0
SFR Address:
0xA5
Bits7–0: Output Configuration Bits for P1.7–P1.0 (respectively): ignored if corresponding bit in regis-
ter P1MDIN is logic 0.
0: Corresponding P1.n Output is open-drain.
1: Corresponding P1.n Output is push-pull.
SFR Definition 14.12. P1SKIP: Port1 Skip
R/W
Bit7
R/W
Bit6
R/W
Bit5
R/W
Bit4
R/W
Bit3
R/W
Bit2
R/W
Bit1
R/W
Reset Value
00000000
Bit0
SFR Address:
0xD5
Bits7–0: P1SKIP[7:0]: Port1 Crossbar Skip Enable Bits.
These bits select Port pins to be skipped by the Crossbar Decoder. Port pins used as ana-
log inputs (for ADC or Comparator) or used as special functions (V
input, external oscil-
REF
lator circuit, CNVSTR input) should be skipped by the Crossbar.
0: Corresponding P1.n pin is not skipped by the Crossbar.
1: Corresponding P1.n pin is skipped by the Crossbar.
130
Rev. 0.3
