MS18R1622(4/8)DH0
Standard SO-RIMM Module Marking
Information contained on the label is specific to the SO-
RIMM module and provides RDRAM device information
without requiring removal of the SO-RIMM module’s heat
spreader.
The SO-RIMM modules available from Samsung are
marked like Figure 5 below. This marking also assists users
to specify and verify if the correct SO-RIMM modules are
installed in their systems. In the diagram, a label is shown
attached to the SO-RIMM module’s heat spreader.
A
C
E
F
G
B
D
KOREA 0245 256MB /8 ECC
MS18R1628DH0-CN9 1066-32 052
L
K
J
I
H
Label Field
Description
Marked Text
SAMSUNG
Unit
A
B
Vendor Logo
Country
SO-RIMM Module Vendor SAMSUNG Logo Area
Country of origin
-
-
KOREA
yyww
Year & Week
code
C
D
E
F
Manufactured Year & Week code
-
Module Memory
Capacity
Number of 8-bit or 9-bit MBytes of RDRAM storage in
SO-RIMM module
64MB, 128MB, 256MB
2/4/8
MBytes
Number of
RDRAM devices
Number of RDRAM devices contained in the SO-RIMM
module
RDRAM
devices
Indicates whether the SO-RIMM module supports 9 (ECC)
bit Bytes
ECC Support
ECC = 9 bit Bytes
-
G
H
Notice!
Hot surface caution notice.
ISO Standard
-
-
-
-
Caution Logo
Gerber : 05 = 0.5 ver
09 = 0.9 ver
Gerber & SPD
Version
PCB Gerber file & SPD code version used on SO-RIMM
Module
I
-
SPD
: 2 = 1.3 ver.
J
tRAC
Row Access Time
-32P, 32, -35, -40, -45
1066, 800
ns
MHz
-
K
L
Memory Speed
Part No.
Data transfer speed for RDRAM device
SAMSUNG SO-RIMM Module part No.
See Table 1
Figure 5: SO-RIMM Module Marking Example
Rev. 1.0 July 2002
Page12
