OneNAND512Mb(KFG1216U2B-xIB6)
FLASH MEMORY
6.16
NAND Flash Core Reset Timing
See AC Characteristics Table 5.6
AVD
F220h
A0~A15
DQ0~DQ15
CE
00F0h
OE
WE
tReady2
INT
bit
High-Z
RDY
OneNAND
Operation
Idle
Operation or Idle
NAND Flash Core reset
6.17 Data Protection Timing During Power Down
The device is designed to offer protection from any involuntary program/erase during power-transitions. RP pin provides hardware
protection and must be kept at VIL before Vcc drops to 1.8V
typ. 1.8V
VCC
0V
RP
INT
OneNAND
Operation
OneNAND Logic Reset & NAND Array Write Protected
113
