OneNAND512Mb(KFG1216U2B-xIB6)
FLASH MEMORY
6.13
Cold Reset Timing
Vcc =2.5V
System Power
1)
Bootcode - copy done
Idle
OneNAND
Operation
Sleep
Bootcode copy
2)
RP
High-Z
INT
3)
INT bit
0 (default)
1
IOBE bit
0 (default)
1 (default)
1
INTpol bit
Note: 1) Bootcode copy operation starts after 400us from the moment that Vcc reaches 2.5V.
2) 1K bytes Bootcode copy takes 70us(estimated) from sector0 and sector1/page0/block0 of NAND Flash array to BootRAM.
Host can read Bootcode in BootRAM(1K bytes) after Bootcode copy completion.
3) INT register goes ‘Low’ to ‘High’ on the condition of ‘Bootcode-copy done’ and RP rising edge.
If RP goes ‘Low’ to ‘High’ before ‘Bootcode-copy done’, INT register goes to ‘Low’ to ‘High’ as soon as ‘Bootcode-copy done’
110
