RT6263A/B
Outline Dimension
Dimensions In Millimeters
Dimensions In Inches
Symbol
Min
Max
Min
Max
A
A1
B
0.700
0.000
1.397
0.220
2.591
2.692
0.585
0.080
0.300
1.000
0.100
1.803
0.380
3.000
3.099
0.715
0.254
0.610
0.028
0.000
0.055
0.009
0.102
0.106
0.023
0.003
0.012
0.039
0.004
0.071
0.015
0.118
0.122
0.028
0.010
0.024
b
C
D
e
H
L
TSOT-23-8 (FC) Surface Mount Package
