Register 0x0FE, 0x1FE, 0x2FE, 0x3FE, 0x4FE, 0x5FE, 0x6FE, 0x7FE:
Channel Serial Interface Configuration
Bit
Type
Function
Unused
Unused
Reserved
Reserved
Reserved
Reserved
TXDINV
RXDINV
Default
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
X
X
0
0
1
1
0
0
R/W
R/W
R/W
R/W
R/W
R/W
RXDINV:
The receive inversion RXDINV controls the polarity of the receive data. When RXDINV is
set high, the polarity of the RXD+/- is inverted. When RXDINV is set low, the RXD+/-
inputs operate normally.
TXDINV:
The transmit inversion TXDINV controls the polarity of the transmit data. When TXDINV
is set high, the polarity of the TXD+/- is inverted. when TXDINV is set low, the TXD+/-
outputs operate normally.
Reserved
All reserved bits must be programmed to default values for proper operation.
