Register 0x0F6, 0x1F6, 0x2F6, 0x3F6, 0x4F6, 0x5F6, 0x6F6, 0x7F6:
RASE Receive K2
Bit
Type
Function
K2[7]
K2[6]
K2[5]
K2[4]
K2[3]
K2[2]
K2[1]
K2[0]
Default
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
R
R
R
R
R
R
R
R
X
X
X
X
X
X
X
X
K2[7:0]:
The K2[7:0] bits contain the current K2 code value. The contents of this register are
updated when a new K2 code value (different from the current K2 code value) has been
received for three consecutive frames. An interrupt may be generated when a new code
value is received (using the COAPSE bit in the RASE Interrupt Enable Register). K2[7] is
the most significant bit corresponding to bit 1, the first bit received. K2[0] is the least
significant bit, corresponding to bit 8, the last bit received.
