S/UNI®-8x155 ASSP Telecom Standard Product Data Sheet
Released
Register 0x0FD, 0x1FD, 0x2FD, 0x3FD, 0x4FD, 0x5FD, 0x6FD, 0x7FD:
Channel Concatenation Interrupt Status
Bit
Type
Function
Unused
Unused
Unused
Unused
Unused
Unused
AISCI
Default
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
X
X
X
X
X
X
X
X
R
R
LOPCI
LOPCI:
A logic one on the LOPCI bit indicates that a transition has occurred on the Loss of Pointer
Concatenation indicator. This bit is cleared when this register is read.
AISCI:
A logic one on the AISCI bit indicates that a transition has occurred on the Pointer AIS
indicator. This bit is cleared when this register is read.
Proprietary and Confidential to PMC-Sierra, Inc., and for its customers’ internal use.
Document No.: PMC- 2010299, Issue 2
300
