S/UNI®-8x155 ASSP Telecom Standard Product Data Sheet
Released
Register 0x0F5, 0x1F5, 0x2F5, 0x3F5, 0x4F5, 0x5F5, 0x6F5, 0x7F5:
RASE Receive K1
Bit
Type
Function
K1[7]
K1[6]
K1[5]
K1[4]
K1[3]
K1[2]
K1[1]
K1[0]
Default
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
R
R
R
R
R
R
R
R
X
X
X
X
X
X
X
X
K1[7:0]:
The K1[7:0] bits contain the current K1 code value. The contents of this register are
updated when a new K1 code value (different from the current K1 code value) has been
received for three consecutive frames. An interrupt may be generated when a new code
value is received (using the COAPSE bit in the RASE Interrupt Enable Register). K1[7] is
the most significant bit corresponding to bit 1, the first bit received. K1[0] is the least
significant bit, corresponding to bit 8, the last bit received.
