S/UNI®-8x155 ASSP Telecom Standard Product Data Sheet
Released
Register 0x0EF, 0x1EF, 0x2EF, 0x3EF, 0x4EF, 0x5EF, 0x6EF, 0x7EF:
RASE SD Saturation Threshold LSB
Bit
Type
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Function
SDSTH[7]
SDSTH[6]
SDSTH[5]
SDSTH[4]
SDSTH[3]
SDSTH[2]
SDSTH[1]
SDSTH[0]
Default
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
0
0
0
0
0
0
0
Register 0x0F0, 0x1F0, 0x2F0, 0x3F0, 0x4F0, 0x5F0, 0x6F0, 0x7F0:
RASE SD Saturation Threshold MSB
Bit
Type
Function
Unused
Unused
Unused
Unused
SDSTH[11]
SDSTH[10]
SDSTH[9]
SDSTH[8]
Default
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
X
X
X
X
0
0
0
0
R/W
R/W
R/W
R/W
SDSTH[11:0]:
The SDSTH[11:0] value represents the allowable number of B2 errors that can be
accumulated during an evaluation window before an SD threshold event is declared.
Setting this threshold to 0xFFF disables the saturation functionality. Refer to the
Operations section for the recommended settings.
