S/UNI®-8x155 ASSP Telecom Standard Product Data Sheet
Released
Register 0x0F3, 0x1F3, 0x2F3, 0x3F3, 0x4F3, 0x5F3, 0x6F3, 0x7F3:
RASE SD Clearing Threshold LSB
Bit
Type
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Function
SDCTH[7]
SDCTH[6]
SDCTH[5]
SDCTH[4]
SDCTH[3]
SDCTH[2]
SDCTH[1]
SDCTH[0]
Default
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
0
0
0
0
0
0
0
Register 0x0F4, 0x1F4, 0x2F4, 0x3F4, 0x4F4, 0x5F4, 0x6F4, 0x7F4:
RASE SD Clearing Threshold MSB
Bit
Type
Function
Unused
Unused
Unused
Unused
SDCTH[11]
SDCTH[10]
SDCTH[9]
SDCTH[8]
Default
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
X
X
X
X
0
0
0
0
R/W
R/W
R/W
R/W
SDCTH[11:0]:
The SDCTH[11:0] value determines the threshold for the removal of the SD alarm. The SD
alarm is removed when the number of B2 errors accumulated during an evaluation window
is less than the SDCTH[11:0] value. Refer to the Operations section for the recommended
settings.
Proprietary and Confidential to PMC-Sierra, Inc., and for its customers’ internal use.
Document No.: PMC- 2010299, Issue 2
295
