PCI Express Configuration, Control, and Status
Registers
The PCI Express Configuration, Control, and Status registers that can be initialized are discussed in the
following sections. However, this is not a complete list of programmable registers. For a complete list,
refer to Chapter 11, “PEX 8532 Transparent Mode Port Registers,” and Appendix A, “Serial EEPROM
Memory Map.”
• Section 5.3.1, “Selecting Configuration Values Using Serial EEPROM”
• Section 5.3.2, “Selecting Upstream Port Using Serial EEPROM”
• Section 5.3.3, “Setting Port Configuration Using Serial EEPROM”
• Section 5.3.4, “Power Management Parameters Using Serial EEPROM”
• Section 5.3.5, “Message Signaled Interrupt Capability Using Serial EEPROM”
• Section 5.3.6, “PCI Express Capability Using Serial EEPROM”
• Section 5.3.7, “Device Serial Number Extended Capability Using Serial EEPROM”
• Section 5.3.8, “Power Budgeting Extended Capability Using Serial EEPROM”
• Section 5.3.9, “Virtual Channel Extended Capability Using Serial EEPROM”
• Section 5.3.10, “Advanced Error Reporting Capability Using Serial EEPROM”
The Device-Specific registers cannot be accessed by Configuration requests; however, software can
access these registers with Memory requests.
