MT9M021, MT9M031
Table 9. I/O FALL SLEW RATE (2.8 V VDD_IO) (Note 1)
Parallel Slew (R0x306E[15:13])
Condition
Default
Default
Default
Default
Default
Default
Default
Default
Min
1.00
0.76
0.60
0.46
0.35
0.25
0.17
0.11
Typ
1.62
1.24
0.98
0.75
0.56
0.40
0.27
0.16
Max
2.41
1.88
1.50
1.16
0.86
0.61
0.41
0.24
Unit
V/ns
V/ns
V/ns
V/ns
V/ns
V/ns
V/ns
V/ns
7
6
5
4
3
2
1
0
1. Minimum and maximum values are taken at the temperature and voltage limits; for instance, 70°C ambient at 90% of V _IO, and −30°C
DD
at 110% of V _IO. All values are taken at the 50% transition point. The loading used is 20 pF.
DD
Table 10. I/O RISE SLEW RATE (1.8 V VDD_IO) (Note 1)
Parallel Slew (R0x306E[15:13])
Condition
Default
Default
Default
Default
Default
Default
Default
Default
Min
0.41
0.30
0.24
0.19
0.14
0.10
0.07
0.04
Typ
0.65
0.47
0.37
0.28
0.21
0.15
0.10
0.06
Max
1.10
0.79
0.61
0.46
0.34
0.24
0.16
0.10
Unit
V/ns
V/ns
V/ns
V/ns
V/ns
V/ns
V/ns
V/ns
7
6
5
4
3
2
1
0
1. Minimum and maximum values are taken at the temperature and voltage limits; for instance, 70°C ambient at 90% of V _IO, and −30°C
DD
at 110% of V _IO. All values are taken at the 50% transition point. The loading used is 20 pF.
DD
Table 11. I/O FALL SLEW RATE (1.8 V VDD_IO) (Note 1)
Parallel Slew (R0x306E[15:13])
Condition
Default
Default
Default
Default
Default
Default
Default
Default
Min
0.42
0.32
0.26
0.20
0.16
0.12
0.08
0.05
Typ
0.68
0.51
0.41
0.32
0.24
0.18
0.12
0.07
Max
1.11
0.84
0.67
0.52
0.39
0.28
0.19
0.11
Unit
V/ns
V/ns
V/ns
V/ns
V/ns
V/ns
V/ns
V/ns
7
6
5
4
3
2
1
0
1. Minimum and maximum values are taken at the temperature and voltage limits; for instance, 70°C ambient at 90% of V _IO, and −30°C
DD
at 110% of V _IO. All values are taken at the 50% transition point. The loading used is 20 pF.
DD
