Power Consumption Benchmark
M_LF EQU 15
M_FV EQU 16
M_SA EQU 17
M_CE EQU 19
M_SM EQU 20
M_RM EQU 21
M_CP0 EQU 22
M_CP1 EQU 23
; DO-Loop Flag
; DO-Forever Flag
; Sixteen-Bit Arithmetic
; Instruction Cache Enable
; Arithmetic Saturation
; Rounding Mode
; bit 0 of priority bits in SR
; bit 1 of priority bits in SR
;
control and status bits in OMR
M_CDP EQU $300 ; mask for CORE-DMA priority bits in OMR
M_MA
M_MB
M_MC
M_MD
equ0
equ1
equ2
equ3
; Operating Mode A
; Operating Mode B
; Operating Mode C
; Operating Mode D
M_EBD EQU 4
M_SD EQU 6
; External Bus Disable bit in OMR
; Stop Delay
M_MS EQU 7
; Memory Switch bit in OMR
; bit 0 of priority bits in OMR
; bit 1 of priority bits in OMR
M_CDP0 EQU 8
M_CDP1 EQU 9
M_BEN
EQU 10 ; Burst Enable
M_TAS EQU 11 ; TA Synchronize Select
M_BRT EQU 12 ; Bus Release Timing
M_ATE EQU 15
M_XYS EQU 16
M_EUN EQU 17
M_EOV EQU 18
M_WRP EQU 19
M_SEN EQU 20
; Address Tracing Enable bit in OMR.
; Stack Extension space select bit in OMR.
; Extensed stack UNderflow flag in OMR.
; Extended stack OVerflow flag in OMR.
; Extended WRaP flag in OMR.
; Stack Extension Enable bit in OMR.
;*************************************************************************
;
;
;
;
;
EQUATES for DSP56303 interrupts
Last update: June 11 1995
;*************************************************************************
page
opt
132,55,0,0,0
mex
intequ ident
if
1,0
@DEF(I_VEC)
;leave user definition as is.
else
I_VEC EQU $0
endif
;------------------------------------------------------------------------
; Non-Maskable interrupts
;------------------------------------------------------------------------
I_RESET EQU I_VEC+$00 ; Hardware RESET
I_STACK EQU I_VEC+$02 ; Stack Error
I_ILL EQU I_VEC+$04
I_DBG EQU I_VEC+$06
I_TRAP EQU I_VEC+$08
I_NMI EQU I_VEC+$0A
; Illegal Instruction
; Debug Request
; Trap
; Non Maskable Interrupt
;------------------------------------------------------------------------
; Interrupt Request Pins
;------------------------------------------------------------------------
I_IRQA EQU I_VEC+$10
I_IRQB EQU I_VEC+$12
I_IRQC EQU I_VEC+$14
I_IRQD EQU I_VEC+$16
; IRQA
; IRQB
; IRQC
; IRQD
;------------------------------------------------------------------------
; DMA Interrupts
;------------------------------------------------------------------------
I_DMA0 EQU I_VEC+$18
I_DMA1 EQU I_VEC+$1A
I_DMA2 EQU I_VEC+$1C
I_DMA3 EQU I_VEC+$1E
; DMA Channel 0
; DMA Channel 1
; DMA Channel 2
; DMA Channel 3
A-11
