M_DDR2 EQU $FFFFE6 ; DMA2 Destination Address Register
M_DCO2 EQU $FFFFE5 ; DMA2 Counter
M_DCR2 EQU $FFFFE4 ; DMA2 Control Register
;
Register Addresses Of DMA4
M_DSR3 EQU $FFFFE3 ; DMA3 Source Address Register
M_DDR3 EQU $FFFFE2 ; DMA3 Destination Address Register
M_DCO3 EQU $FFFFE1 ; DMA3 Counter
M_DCR3 EQU $FFFFE0 ; DMA3 Control Register
;
Register Addresses Of DMA4
M_DSR4 EQU $FFFFDF ; DMA4 Source Address Register
M_DDR4 EQU $FFFFDE ; DMA4 Destination Address Register
M_DCO4 EQU $FFFFDD ; DMA4 Counter
M_DCR4 EQU $FFFFDC ; DMA4 Control Register
;
Register Addresses Of DMA5
M_DSR5 EQU $FFFFDB ; DMA5 Source Address Register
M_DDR5 EQU $FFFFDA ; DMA5 Destination Address Register
M_DCO5 EQU $FFFFD9 ; DMA5 Counter
M_DCR5 EQU $FFFFD8 ; DMA5 Control Register
;
DMA Control Register
M_DSS EQU $3
M_DSS0 EQU 0
M_DSS1 EQU 1
M_DDS EQU $C
M_DDS0 EQU 2
M_DDS1 EQU 3
; DMA Source Space Mask (DSS0-Dss1)
; DMA Source Memory space 0
; DMA Source Memory space 1
; DMA Destination Space Mask (DDS-DDS1)
; DMA Destination Memory Space 0
; DMA Destination Memory Space 1
M_DAM EQU $3f0 ; DMA Address Mode Mask (DAM5-DAM0)
M_DAM0 EQU 4 ; DMA Address Mode 0
M_DAM1 EQU 5 ; DMA Address Mode 1
M_DAM2 EQU 6 ; DMA Address Mode 2
M_DAM3 EQU 7 ; DMA Address Mode 3
M_DAM4 EQU 8 ; DMA Address Mode 4
M_DAM5 EQU 9 ; DMA Address Mode 5
M_D3D EQU 10
; DMA Three Dimensional Mode
M_DRS EQU $F800; DMA Request Source Mask (DRS0-DRS4)
M_DCON EQU 16 ; DMA Continuous Mode
M_DPR EQU $60000; DMA Channel Priority
M_DPR0 EQU 17 ; DMA Channel Priority Level (low)
M_DPR1 EQU 18 ; DMA Channel Priority Level (high)
M_DTM EQU $380000; DMA Transfer Mode Mask (DTM2-DTM0)
M_DTM0 EQU 19 ; DMA Transfer Mode 0
M_DTM1 EQU 20 ; DMA Transfer Mode 1
M_DTM2 EQU 21 ; DMA Transfer Mode 2
M_DIE EQU 22
M_DE EQU 23
; DMA Interrupt Enable bit
; DMA Channel Enable bit
;
DMA Status Register
M_DTD EQU $3F ; Channel Transfer Done Status MASK (DTD0-DTD5)
M_DTD0 EQU 0
M_DTD1 EQU 1
M_DTD2 EQU 2
M_DTD3 EQU 3
M_DTD4 EQU 4
M_DTD5 EQU 5
M_DACT EQU
; DMA Channel Transfer Done Status 0
; DMA Channel Transfer Done Status 1
; DMA Channel Transfer Done Status 2
; DMA Channel Transfer Done Status 3
; DMA Channel Transfer Done Status 4
; DMA Channel Transfer Done Status 5
; DMA Active State
8
M_DCH EQU $E00; DMA Active Channel Mask (DCH0-DCH2)
M_DCH0 EQU
M_DCH1 EQU 10 ; DMA Active Channel 1
M_DCH2 EQU 11 ; DMA Active Channel 2
9
; DMA Active Channel 0
;------------------------------------------------------------------------
;
;
;
EQUATES for Phase Locked Loop (PLL)
;------------------------------------------------------------------------
Register Addresses Of PLL
M_PCTL EQU $FFFFFD ; PLL Control Register
PLL Control Register
;
;
