To set up the SPI module for the Enhanced Buffer
Master mode of operation:
To set up the SPI module for the Enhanced Buffer
Slave mode of operation:
1. If using interrupts:
1. Clear the SPIxBUF register.
2. If using interrupts:
a) Clear the SPIxIF bit in the respective IFS
register.
a) Clear the SPIxIF bit in the respective IFS
register.
b) Set the SPIxIE bit in the respective IEC
register.
b) Set the SPIxIE bit in the respective IEC
register.
c) Write the SPIxIP bits in the respective IPC
register.
c) Write the SPIxIP bits in the respective IPC
register to set the interrupt priority.
2. Write the desired settings to the SPIxCON1
and SPIxCON2 registers with MSTEN
(SPIxCON1<5>) = 1.
3. Write the desired settings to the SPIxCON1
and SPIxCON2 registers with MSTEN
(SPIxCON1<5>) = 0.
3. Clear the SPIROV bit (SPIxSTAT<6>).
4. Select Enhanced Buffer mode by setting the
SPIBEN bit (SPIxCON2<0>).
4. Clear the SMP bit.
5. If the CKE bit is set, then the SSEN bit must be
set, thus enabling the SSx pin.
5. Enable SPI operation by setting the SPIEN bit
(SPIxSTAT<15>).
6. Clear the SPIROV bit (SPIxSTAT<6>).
6. Write the data to be transmitted to the SPIxBUF
register. Transmission (and reception) will start
as soon as data is written to the SPIxBUF
register.
7. Select Enhanced Buffer mode by setting the
SPIBEN bit (SPIxCON2<0>).
8. Enable SPI operation by setting the SPIEN bit
(SPIxSTAT<15>).
FIGURE 15-2:
SPIx MODULE BLOCK DIAGRAM (ENHANCED MODE)
SCKx
1:1/4/16/64
Primary
Prescaler
1:1 to 1:8
Secondary
Prescaler
FCY
SSx/FSYNCx
Sync
Control
Select
Edge
Control
Clock
SPIxCON1<1:0>
SPIxCON1<4:2>
Control
Shift
SDOx
SDIx
Enable
Master Clock
bit 0
SPIxSR
Transfer
Transfer
8-Level FIFO
Receive Buffer
8-Level FIFO
Transmit Buffer
SPIxBUF
Write SPIxBUF
Read SPIxBUF
16
Internal Data Bus
2010 Microchip Technology Inc.
DS39951C-page 167
