High-Speed Read Meeting Hold (Minimum Delay)
The following equations show how to calculate the allowed combined propagation delay
range of the SD_CLK and SD_DAT/CMD signals on the PCB.
(12)
tCLK_DELAY + tOH + tDATA_DELAY + tTAP_DELAY > tIH_H
tCLK_DELAY + tDATA_DELAY > tIH_H – tOH – tTAP_DELAY
tCLK_DELAY + tDATA_DELAY > 2 – 2,5 – tTAP_DELAY
tCLK_DELAY + tDATA_DELAY > – 0,5 – tTAP_DELAY
The data + clock delay must be greater than -0.5 ns for a 20 ns clock cycle. This is always
fulfilled.
