OPTIREG™ SBC TLE9274QXV33
General product characteristics
Table 5
Current consumption (cont’d)
Current consumption values are specified at Tj = 25°C, VS = 13.5 V, all outputs open
(unless otherwise specified)
Parameter
Symbol
Values
Typ.
65
Unit Note or Test Condition Number
Min.
Max.
Stop mode current
consumption,
cyclic wake
IStop,C25
–
85
µA
1)2) Tj = 25°C
P_4.4.5
Buck module in PFM
no load on VCC1
VCC2 = OFF;
CAN / LINx = OFF
Watchdog = ON
WK enabled
BOOST = OFF
SBC Sleep mode
Sleep mode current
consumption
ISleep,25
–
–
–
30
80
50
50
–
µA
µA
µA
1) Tj = 25°C
VCC1,VCC2 = OFF
CAN / LINx = OFF,
WK enabled
1)3) Tj = 85°C
VCC1,VCC2 = OFF
CAN / LINx = OFF
WK enabled
P_4.4.6
P_4.4.13
P_4.4.7
Sleep mode current
consumption
ISleep,85
Sleep mode current
consumption,
ISleep,VCC2,25
75
1) Tj = 25°C
VCC1= OFF
VCC2 enabled
VS2 = VS
VCC2 = ON (no load)
CAN / LINx = OFF
WK enabled
Incremental current consumption
Current consumption for ICAN,rec
CAN, recessive state
–
–
–
2
3
1
3
mA
mA
mA
VCAN = VCC2
P_4.4.8
P_4.4.14
P_4.4.9
SBC Normal mode
CAN Normal mode
VTXDCAN = 5 V
no RL on CAN
Current consumption for ICAN,dom
CAN, dominant state
4.5
2
3)VCAN = 5V
SBC Normal mode
CAN Normal mode
VTXDCAN = GND
no RL on CAN
1) VCAN = VCC2
SBC Normal / Stop mode
CAN Receive-Only mode
VTXDCAN = 5 V
Current consumption for ICAN,RevOnly
CAN module,
Receive-Only mode
no RL on CAN
Datasheet
17
Rev.2.0
2022-05-06
