OPTIREG™ SBC TLE9274QXV33
General product characteristics
4.4
Current consumption
Table 5
Current consumption
Current consumption values are specified at Tj = 25°C, VS = 13.5 V, all outputs open
(unless otherwise specified)
Parameter
Symbol
Values
Typ.
Unit Note or Test Condition Number
Min.
Max.
SBC Normal mode
Normal mode current
consumption
INormal
–
5
10
mA
µA
5.5 V < VS < 28 V
no load on VCC1
Tj = -40°C to +150°C
VCC2 / CAN / LIN / BOOST
= OFF
P_4.4.1
P_4.4.2
SBC Stop mode
Stop mode current
consumption
IStop,25
–
–
–
50
65
1)2) Tj = 25°C
Buck module in PFM
no load on VCC1
VCC2 = OFF;
CAN / LINx = OFF
Watchdog = OFF
WK enabled
BOOST = OFF
1)2)3) Tj = 85°C;
Stop mode current
consumption
IStop,85
95
70
–
µA
µA
P_4.4.3
P_4.4.4
Buck module in PFM
no load on VCC1
VCC2 = OFF;
CAN / LINx = OFF
Watchdog = OFF
WK enabled
BOOST = OFF
1)2) Tj = 25°C
Buck module in PFM
no load on VCC1
VS2 = VS
Stop mode current
consumption,
VCC2 enabled
IStop,VCC2,25
95
VCC2 = ON (no load); CAN
/ LINx = OFF
Watchdog = OFF
WK enabled
BOOST = OFF
Datasheet
16
Rev.2.0
2022-05-06
