TLD7002-16ES

Datasheet

6 Power Stage

PWM.OUTn

t_{ON_fast/normal}

t_OUTnPW

I_OUT

90ꢀ of I_OUT

(dI/dt)_ON

(dI/dt)_OFF

t_{OFF_fast/normal}

10ꢀ of I_OUT

Figure 12

Output stage timing definition

6.11

Electrical characteristics

Table 15

Electrical Characteristics

V_S= 6 V to 20 V, T_J= -40°C to +150°C, all voltages with respect to ground, positive currents flowing as described

in Figure 2 (unless otherwise specified). Typical values: V_S= 9 V, T_J= 25°C

Parameter

Symbol

Values

Typ.

Unit

Note or condition

P-

Number

Min.

Max.

Leakage currents

Output leakage current I_{OUT_LEAK}

–

µA

T_J= 85°C,

V_OUT≤ 20 V,

idle mode

PRQ-428

PRQ-429

Output leakage current I_{OUT_LEAK}

–

T_J≤ 150°C,

V_OUT≤ 20 V,

idle mode

Output current accuracy and drop-out voltage

Output current

accuracy

A_IOUT,25

-5

–

ꢀ

T_J≥ 25°C full scale

PRQ-430

PRQ-431

range, where 10.125

mA (code 0x4) ≤ I_OUT

< 76.5 mA (code 0x3F)

Output current

accuracy

A_IOUT

-10

-40°C ≤ T_J< 150°C

full scale range, where

5.625 mA (code 0x00)

≤ I_OUT< 76.5 mA (code

0x3F)

Output current ripple ΔI_OUT

-1.8

–

1.8

I_{OUTn_tPWMn-1}

PRQ-436

I_{OUTn_tPWMn}, output

current diﬀerence

between two

consecutive periods

(table continues...)

Datasheet

Rev.1.00

2022-05-03
