TLD7002-16ES

Datasheet

6 Power Stage

Table 15

(continued) Electrical Characteristics

V_S= 6 V to 20 V, T_J= -40°C to +150°C, all voltages with respect to ground, positive currents flowing as described

in Figure 2 (unless otherwise specified). Typical values: V_S= 9 V, T_J= 25°C

Parameter

Symbol

Values

Typ.

Unit

Note or condition

P-

Number

Min.

Max.

Turn-on time (GPIN)

t_ON

–

I_OUT> 90ꢀ of desired PRQ-834

output current afer

GPIN="high" at f_PWM

≥

300 Hz and t_PHS< 100

µs;

GPIN encoding

enabled;

GPIN is processed

afer HSLI

communication is

finished

Protection

Thermal current

derating accuracy

a_TJDER

-5

–

Not subject to

production test -

specified by design

PRQ-451

PRQ-452

PRQ-449

PRQ-450

Thermal current

derating stop

temperature

TJ_STOP

T_J(ABS)

T_HYS(ABS)

155

150

165

175

200

°C

specified by design

- not subject to

production test

Thermal shutdown

temperature

Not subject to

production test -

specified by design

Thermal shutdown

hysteresis

specified by design

Datasheet

Rev.1.00

2022-05-03
