TC39x BC/BD-Step
Electrical SpecificationEBU Timings
Table 3-73 Burst Read Timings valid for 3.3V (cont’d)
Parameter
Symbol
Values
Typ.
Unit
Note / Test Condition
Min.
Max.
WAIT setup (low or high) to
BFCLKI rising edge
t
t
25 SR
26 SR
5
-
-
ns
ns
CL=35pF
CL=35pF
WAIT hold (low or high) from
BFCLKI rising edge
0
-
-
Address
Phase(s)
Command
Phase(s)
Burst
Phase(s)
Burst
Phase(s)
Recovery
Phase(s)
Next Addr.
Phase(s)
BFCLKI
1)
BFCLKO
t10
t10
Next
A[23:0]
Burst Start Address
Addr.
t22
t22
t22
ADV
t21
t21
t21
CS[3:0]
CSCOMB
t12
t12
t22a
t24
RD
RD/WR
t22a
BAA
t24
t23
t23
D[31:0]
(32-Bit)
Data (Addr+0)
Data (Addr+4)
D[15:0]
(16-Bit)
Data (Addr+0)
Data (Addr+2)
t26
t25
WAIT
1)
Output delays are always referenced to BCLKO. The reference clock for input
characteristics depends on bit EBU_BFCON.FDBKEN.
EBU_BFCON.FDBKEN = 0: BFCLKO is the input reference clock.
EBU_BFCON.FDBKEN = 1: BFCLKI is the input reference clock (EBU clock
feedback enabled).
BurstRDWR_4.vsd
Figure 3-28 EBU Burst Mode Read / Write Access Timing
Data Sheet
508
V 1.2, 2021-03
OPEN MARKET VERSION
