TC39x BC/BD-Step
Electrical SpecificationRadar Interface Timing
3.30
Radar Interface Timing
This section defines the timings for RIF in the TC39x.
Table 3-68 Skew Calibration Related
Parameter
Symbol
Values
Typ.
Unit
Note / Test Condition
Min.
2.5
0.8
0.8
30
Max.
Bit time
t
t
t
t
80 CC
82 SR
83 SR
88 SR
-
-
-
-
-
-
-
-
ns
ns
ns
ns
Set-up time
Hold time
RAMP1 set-up time relative to
the FRAME rising edge
RAMP1 hold time relative to the t89 SR
30
-
-
ns
FRAME rising edge
Data Sheet
502
V 1.2, 2021-03
OPEN MARKET VERSION
