S29GL01GP
S29GL512P
S29GL256P
S29GL128P
Figure 11.9 Program Operation Timings
Program Command Sequence (last two cycles)
Read Status Data (last two cycles)
tAS
PA
tWC
Addresses
555h
PA
PA
tAH
CE#
OE#
tCH
tWHWH1
tWP
WE#
Data
tWPH
tCS
tDS
tDH
PD
DOUT
A0h
Status
tBUSY
tRB
RY/BY#
VCC
tVCS
Notes
1. PA = program address, PD = program data, DOUT is the true data at the program address.
2. Illustration shows device in word mode.
Figure 11.10 Accelerated Program Timing Diagram
VHH
VIL or VIH
VIL or VIH
ACC
tVHH
tVHH
Notes
1. Not 100% tested.
2. CE#, OE# = VIL
3. OE# = VIL
4. See Figure 11.3 and Table for test specifications.
Document Number: 002-00886 Rev. *B
Page 57 of 83
