EZ-PD™ CCG7D Automotive USB Type-C and Buck-boost Controller
Dual-port
Electrical specifications
6
Electrical specifications
6.1
Table 7
Absolute maximum ratings
Absolute maximum ratings[1]
Parameter
Description
Min
Typ
Max
Unit Details/conditions
Maximum input supply
voltage
VIN_MAX
40
Maximum supply voltage
relative to VSS
Maximum supply voltage
relative to VSS
VDDD_MAX
V5V_MAX
6
–
V
–
Max VBUS_C (P0/P1) voltage
relative to Vss
Max voltage on CC1 and CC2
pins
VBUS_C_MAX
24
VCC_PIN_ABS
VGPIO_ABS
Inputs to GPIO
VDDD + 0.5
–0.5
–25
–
VGPIO_OVT_ABS OVT GPIO voltage
IGPIO_ABS Maximum current per GPIO
6
25
GPIO injection current, Max
mA
V
Absolute max, current
injected per pin
IGPIO_INJECTION for VIH > VDDD, and Min for VIL <
VSS
–0.5
0.5
–
Electrostatic discharge
ESD_HBM
2000
500
All pins.
human body model
Electrostatic discharge (ESD)
Charged device model
ESD
ESD_CDM
charged device model
LU
TJ
Pin current for latch-up
Junction temperature
–100
–40
100
125
mA
°C
–
Note
1. Usage above the absolute maximum conditions listed in Table 7 may cause permanent damage to the
device. Exposure to absolute maximum conditions for extended periods of time may affect device reliability.
The maximum storage temperature is 150 °C in compliance with JEDEC Standard JESD22-A103, High
Temperature Storage Life. When used below absolute maximum conditions but above normal operating
conditions, the device may not operate to specification.
