PROFET + 24V
BTT6200-4ESA
Power stage
VBAT
VS
Gate
driver
Device
logic
VINV
INV
Comp.
IL(INV)
OUT
GND
ZGND
inverse current.vsd
Figure 14
Inverse current circuitry
5.5
Electrical characteristics - power stage
Table 6
Electrical characteristics: Power stage
VS = 8 V to 36 V, TJ = -40°C to 150°C (unless otherwise specified).
Typical values are given at VS = 28 V, TJ = 25°C
Parameter
Symbol
Values
Typ.
Unit Note or Test
Condition
Number
Min.
ON-state resistance per channel RDS(ON)_150 300
Max.
400
360
mΩ
IL = IL4 = 1 A
VIN = 4.5 V
P_5.5.1
TJ = 150°C
See Figure 9
ON-state resistance per channel RDS(ON)_25
–
–
200
1.5
–
–
mΩ
A
10)TJ = 25 °C
10) TA = 85°C
TJ < 150°C
P_5.5.21
P_5.5.2
Nominal load current One
channel active
IL(NOM)1
Nominal load current All
channels active
IL(NOM)2
–
–
1
–
A
P_5.5.3
P_5.5.4
Output voltage drop limitation at VDS(NL)
10
22
mV
IL = IL0 = 25 mA
small load currents
See Chapter 9.3
Drain to source clamping voltage VDS(AZ)
65
–
70
75
V
IDS = 5 mA
See Figure 12
See Chapter 9.1
11)
P_5.5.5
P_5.5.6
VDS(AZ) = [VS - VOUT
]
Output leakage current per
IL(OFF)
0.1
0.5
µA
V floating
IN
channel TJ ≤ 85 °C
VOUT = 0 V
TJ ≤ 85°C
10
Not subject to production test, specified by design.
Test at TJ = -40°C only
11
Datasheet
18
Rev. 1.00
2019-03-09
