AN985B/BX
Registers and Descriptors Description
2. Offset value is from 0-255 (8-bit width).
3. To load the whole wake-up frame-filtering information, consecutive 25 long words write operation to CSR14
should be done.
Watchdog Timer
WTMR_CSR15
Watchdog Timer
Offset
78H
Reset Value
0000 0000H
ꢀꢁ ꢀꢂ ꢃꢄ ꢃꢅ ꢃꢆ ꢃꢇ ꢃꢈ ꢃꢉ ꢃꢀ ꢃꢃ ꢃꢁ ꢃꢂ ꢁꢄ ꢁꢅ ꢁꢆ ꢁꢇ ꢁꢈ ꢁꢉ ꢁꢀ ꢁꢃ ꢁꢁ ꢁꢂ ꢄ
ꢅ
ꢆ
ꢇ
ꢈ
ꢉ
ꢀ
ꢃ
ꢁ
ꢂ
&% 5[ 5[
5:5:5H -&
5 ' V /.
-%
'
&6
5HV
UR
1-
6
6 5H
Field
Bits
Type
Description
CS
31
ro/ee16 Clock Save Mode
h[3]
0B
1B
, clock stuck at 0 when clock save mode enable
, clock stuck at 1 when clock save mode enable
CBS
RxS
30
29
28
ro/ee16 CARDBUS Save Mode
h[2] 1B , CARDBUS clock save mode enable
ro/ee16 Rx Save Mode
h[1] 1B , RX save mode enable
RxRe
ro/ee16 Rx Clock Reverse Mode
h[0]
ro
1B
, reverse (for NS HomePHY mode)
Res
RWR
27:6
5
Reserved
rw
Receive Watchdog Release
The time of release watchdog timer from last carrier deserted.
0B
1B
, 24 bit-time
, 48 bit-time
RWD
4
rw
Receive Watchdog Disable
0B
, If the receiving packet’s length is longer than 2560 bytes the
watchdog timer will be expired
1B
, disable the receive watchdog
Res
JCLK
3
2
ro
rw
Reserved
Jabber Clock
0B
1B
, cut off transmission after 2.6 ms (100 Mbit/s) or 26 ms (10 Mbit/s)
, cut off transmission after 2560 byte-time
NJ
1
0
rw
rw
Non-Jabber
0B
, if jabber expired re-enable transmit function after 42 ms
(100 Mbit/s) or 420 ms (10 Mbit/s)
, immediately re-enable the transmit function after jabber expired
1B
JBD
Jabber Disable
1B , disable transmit jabber function
Data Sheet
65
Rev. 1.51, 2005-11-30
