AN985B/BX
Registers and Descriptors Description
Driver Space for Special Purpose
DS_CR16
Driver Space for Special Purpose
Offset
40H
Reset Value
0000 XX00H
ꢀꢁ ꢀꢂ ꢃꢄ ꢃꢅ ꢃꢆ ꢃꢇ ꢃꢈ ꢃꢉ ꢃꢀ ꢃꢃ ꢃꢁ ꢃꢂ ꢁꢄ ꢁꢅ ꢁꢆ ꢁꢇ ꢁꢈ ꢁꢉ ꢁꢀ ꢁꢃ ꢁꢁ ꢁꢂ ꢄ
ꢅ ꢆ ꢇ ꢈ ꢉ ꢀ ꢃ ꢁ ꢂ
5HV
UR
'6
5HV
UR
UZ
Field
Res
DS
Bits
31:16
15:8
Type
ro
rw
Description
Reserved
Driver Space for special purpose
Since this area won’t be cleared in the software reset. The AN985B/BX
driver can use this rw area for special purpose.
Res
7:0
ro
Reserved
Signature of AN985B/BX
Hard wired register, read only
SIG_CR32
Signature
Offset
80H
Reset Value
0985 1317H
ꢀꢁ ꢀꢂ ꢃꢄ ꢃꢅ ꢃꢆ ꢃꢇ ꢃꢈ ꢃꢉ ꢃꢀ ꢃꢃ ꢃꢁ ꢃꢂ ꢁꢄ ꢁꢅ ꢁꢆ ꢁꢇ ꢁꢈ ꢁꢉ ꢁꢀ ꢁꢃ ꢁꢁ ꢁꢂ ꢄ
ꢅ ꢆ ꢇ ꢈ ꢉ ꢀ ꢃ ꢁ ꢂ
','
9,'
UR
UR
Field
Bits
Type
Description
DID
31:16
ro
Device ID
The device ID number of AN985B/BX.
VID
15:0
ro
Vendor ID
The vendor ID number of ADM Technology Corp.
