2ED2110S06M
650 V high-side and low-side driver with integrated bootstrap diode
6
Parameters Trend Charts
Figures illustrated in this chapter provide information on the experimental performance of the 2ED2110S06M.
The line plotted in each figure is generated from actual lab data unless otherwise specified. A large number of
individual samples were tested sweeping VDD, VBIAS and temperature in order to generate the experimental
curve. The individual data points on the Typ. curve were determined by calculating the averaged experimental
value of each parameter.
Figure 24
Turn-On Delay Time
Figure 25
Turn-Off Delay Time
Figure 26
SD Propagation Delay Time
