ICS1531 Data Sheet - Preliminary
Chapter 6 Register Set
6.5.40 Calibration Registers
The registers in this section can be used to calibrate the ICS1531. Typically, the Calibration registers do not
need to be adjusted. However, access is provided so that production-line calibrations can be made as
necessary.
Note: For information on how to enable the Calibration Regs, see Reg 37:3.
6.5.40.1 Register 38h: R_COMP_OFF
The R_COMP_OFF Register is used to adjust as necessary the comparator offset for the red ‘B’ and ‘A’
channels.
Table 6-39. R_COMP_OFF
Bit Bit Name
Bit Definition
Ac-
cess
Spec. Re-
Func. set
38:7
38:4
R_C_O_B Red Comparator Offset (B Channel).
See
Reg
37:3
–
7
Reserved.
38:3- R_C_O_A Red Comparator Offset (A Channel).
38:0 Reserved.
See
Reg
37:3
–
7
6.5.40.2 Register 39h: G_COMP_OFF
The G_COMP_OFF Register is used to adjust as necessary the comparator offset for the green ‘B’ and ‘A’
channels.
Table 6-40. G_COMP_OFF Register
Bit Bit Name
Bit Definition
Ac-
cess
Spec. Re-
Func. set
39:7
39:4
G_C_O_B Green Comparator Offset (B Channel).
See
Reg
37:3
–
7
Reserved.
39:3- G_C_O_A Green Comparator Offset (A Channel).
39:0 Reserved.
See
Reg
37:3
–
7
6.5.40.3 Register 3Ah: B_COMP_OFF
The B_COMP_OFF Register i is used to adjust as necessary the comparator offset for the blue ‘B’ and ‘A’
channels.
Table 6-41. B_COMP_OFF Register
Bit Bit Name
Bit Definition
Ac-
cess
Spec. Re-
Func. set
3A:7 B_C_O_B Blue Comparator Offset (B Channel).
3A:4 Reserved.
See
Reg
37:3
–
7
3A:3- B_C_O_A Blue Comparator Offset (A Channel).
See
Reg
37:3
–
7
3A:0
Reserved.
ICS1531 Rev N 12/1/99
December, 1999
Copyright © 1999, Integrated Circuit Systems, Inc.
All rights reserved.
52
