ICS1531 Data Sheet - Preliminary
Chapter 6 Register Set
6.5.36 Register 34h: R_FINE
The R_FINE Register is the second adjustment for the red channel of the ADC. It is used to fine tune the
top reference used by the ADC. (See also Section 6.5.33, “Register 31h: R_COARSE”.)
Table 6-35. R_FINE Register
Bit
Bit Name
Bit Definition
Ac- Spec.
cess Func.
Re-
set
34:7-
34:0
R_Fine_ADJ Red Fine Adjust [7-0].
R/W
–
20
[7-0]
These bits adjust the amount of voltage to the top reference of
the red channel of the ADC.
• 0 = Lowest-voltage value
• 255 = Highest-voltage value
6.5.37 Register 35h: G_FINE
The G_FINE Register is the second adjustment for the green channel of the ADC. It is used to fine tune the
top reference used by the ADC. (See also Section 6.5.34, “Register 32h: G_COARSE”.)
Table 6-36. G_FINE Register
Bit
Bit Name
Bit Definition
Ac- Spec.
cess Func.
Re-
set
35:7-
35:0
G_Fine_ADJ Green Fine Adjust [7-0].
[7-0] These bits adjust the amount of voltage to the top reference of
R/W
–
20
the green channel of the ADC.
• 0 = Lowest-voltage value
• 255 = Highest-voltage value
6.5.38 Register 36h: B_FINE
The B_FINE Register is the second adjustment for the blue channel of the ADC. It is used to fine tune the
top reference used by the ADC. (See also Section 6.5.35, “Register 33h: B_COARSE”.)
Table 6-37. B_FINE Register
Bit
Bit Name
Bit Definition
Ac- Spec.
cess Func.
Re-
set
36:7-
36:0
B_Fine_ADJ Blue Fine Adjust [7-0].
R/W
–
20
[7-0]
These bits adjust the amount of voltage to the top reference of
the blue channel of the ADC.
• 0 = Lowest-voltage value
• 255 = Highest-voltage value
ICS1531 Rev N 12/1/99
December, 1999
