ICS1531 Data Sheet - Preliminary

Chapter 6 Register Set

6.5.33 Register 31h: R_COARSE

The R_COARSE Register is the first adjustment for the red channel of the ADC. It is used to coarsely

adjust the analog signal used by the ADC. (See also Section 6.5.36, “Register 34h: R_FINE”.)

Table 6-32. R_COARSE Register

Bit

Bit Name

Bit Definition

Ac- Spec.

cess Func.

Re-

set

^R•^es^S^e^e^rv^e^e^S^d^e^.^{ction 6.1, “Reserved Bits”.}

• ^{These bits can be programmed to ‘0’.}

^R•^es^S^e^e^rv^e^e^S^d^e^.^{ction 6.1, “Reserved Bits”.}

• ^{This bit must be programmed to ‘1’.}

31:7- Reserved

31:6

–

31:5 Reserved

–

^R•^es^S^e^e^rv^e^e^S^d^e^.^{ction 6.1, “Reserved Bits”.}

31:4- Reserved

31:2

–

• ^{These bits can be programmed to ‘0’.}

31:1- R_Coarse_ADJ Red Coarse (Gain) Adjust [1-0].

31:0 [1-0] These bits adjust the red channel of the ADC by adjusting the

R/W

gain of the video amplifier for the analog signal used by the

^A•^DC^{0.= The gain is 1.0 (default).}

• ^{1 = The gain is 1.2.}

• ^{2 = The gain is 1.4 (typical).}

• ^{3 = The gain is 1.6.}

6.5.34 Register 32h: G_COARSE

The G_COARSE Register is the first adjustment for the green channel of the ADC. It is used to coarsely

adjust the analog signal used by the ADC. (See also Section 6.5.37, “Register 35h: G_FINE”.)

Table 6-33. G_COARSE Register

Bit

Bit Name

Bit Definition

Ac- Spec.

cess Func.

Re-

set

^R•^es^S^e^e^rv^e^e^S^d^e^.^{ction 6.1, “Reserved Bits”.}

• ^{These bits can be programmed to ‘0’.}

32:7- Reserved

32:6

–

^R•^es^S^e^e^rv^e^e^S^d^e^.^{ction 6.1, “Reserved Bits”.}

32:5 Reserved

–

• ^{This bit must be programmed to ‘1’.}

^R•^es^S^e^e^rv^e^e^S^d^e^.^{ction 6.1, “Reserved Bits”.}

• ^{These bits can be programmed to ‘0’.}

32:4- Reserved

32:2

–

32:1- G_Coarse_ADJ Green Coarse (Gain) Adjust [1-0].

R/W

32:0 [1-0]

These bits adjust the green channel of the ADC by adjusting

the gain of the video amplifier for the analog signal used by the

^A•^DC^{0.= The gain is 1.0 (default).}

• ^{1 = The gain is 1.2.}

• ^{2 = The gain is 1.4 (typical).}

• ^{3 = The gain is 1.6.}

ICS1531 Rev N 12/1/99

December, 1999
