iC-MR 13-BIT S&H SIN/COS
INTERPOLATOR WITH CONTROLLER INTERFACES
Rev A1, Page 22/44
PH
Addr 0x0D, bit 5:0, Addr 0x0C, bit 7:4
DIAG
Bit
Addr. 0x5A; bit 7...0
Description
R
Code
0x000
0x001
...
Correction angle
+0
Code
0x200
0x201
...
Correction angle
−0
Name
7
RG_MAX
Transmit current control maximum
error
+0.0204
−0.0204
6
AMP_MAX
Amplitude monitoring maximum
error
+0.0204 ∗ PH
+10.42
−0.0204 ∗ PH
−10.42
0x1FF
0x3FF
5
4
DC_MAX
Offset monitoring maximum error
CMP_MAX
Cont. amplitude monitoring
maximum error
Table 25: Phase correction sine vs. cosine
3
2
RG_MIN
Transmit current control minimum
error
AMP_MIN
Amplitude monitoring minimum
error
Diagnostic data
1
0
DC_MIN
Offset monitoring minimum error
The address 0x5A contains diagnosis data. Errors in
signal conditioning (amplitude monitoring) and trans-
mitter current control (ACO) are also reported in er-
ror byte 0x69 as ERR_AMP and ERR_RGL (see page
41).
CMP_MIN
Cont. amplitude monitoring
minimum error
Table 26: Diagnostic register 0x5A
