IBM SONET/SDH Framer
3.6: HShake5, HSMask5 [3824 H Error, 382C H Mask]
Signal Name
IntError
Bits
0
Access
R/W
Default
0
Description
GPP Interface Error (see TOError and IntError Meanings on page 121)
Timeout Error of the GPP interface (see TOError and IntError Meanings on
page 121)
TOError
1
R/W
0
AccViol
PPP
2
3
4
5
6
7
R/W
R/W
R/W
R/W
R/W
R/W
0
0
0
0
0
0
Write access to protected register was attempted
DTACK from PPP stuck at ONE
OFP_Rx4
OFP_Rx3
OFP_Rx2
OFP_Rx1
DTACK from OFP_Rx4 stuck at ONE
DTACK from OFP_Rx3 stuck at ONE
DTACK from OFP_Rx2 stuck at ONE
DTACK from OFP_Rx1 stuck at ONE
ssframer.01
8/27/99
Register Descriptions
Page 123 of 279
