IBM3009K2672
IBM SONET/SDH Framer
2.3: IRQGP3, IRMGP3 [3812 H Request, 381A H Mask]
Signal Name
Bits
Access
Default
Description
Description
Description
IRQHT4
IRQHT3
IRQHT2
IRQHT1
IRQPR4
IRQPR3
IRQPR2
IRQPR1
0
1
2
3
4
5
6
7
R
R
R
R
R
R
R
R
0
0
0
0
0
0
0
0
IRQ from ACH_Tx4
IRQ from ACH_Tx3
IRQ from ACH_Tx2
IRQ from ACH_Tx1
IRQ from PH_Rx4
IRQ from PH_Rx3
IRQ from PH_Rx2
IRQ from PH_Rx1
2.4: IRQGP4, IRMGP4 [3813 H Request, 381B H Mask]
Signal Name
IRQOT4
IRQOT3
IRQOT2
IRQOT1
IRQHR4
IRQHR3
IRQHR2
IRQHR1
Bits
0
Access
Default
R
R
R
R
R
R
R
R
0
0
0
0
0
0
0
0
IRQ from OFP_Tx4
IRQ from OFP_Tx3
IRQ from OFP_Tx2
IRQ from OFP_Tx1
IRQ from ACH_Rx4
IRQ from ACH_Rx3
IRQ from ACH_Rx2
IRQ from ACH_Rx1
1
2
3
4
5
6
7
2.5: IRQGP5, IRMGP5 [3814 H Request, 381C H Mask]
Signal Name
Bits
Access
Default
Reserved
IRQPPP
IRQOR4
IRQOR3
IRQOR2
IRQOR1
2:0
3
R
R
R
R
R
R
000
0
Reserved
IRQ from PPP
4
0
IRQ from OFP_Rx4
IRQ from OFP_Rx3
IRQ from OFP_Rx2
IRQ from OFP_Rx1
5
0
6
0
7
0
Register Descriptions
Page 120 of 279
ssframer.01
8/27/99
IBM [ IBM ]
