IBM3009K2672
IBM SONET/SDH Framer
4.3: ClkStat3, ClkMask3 [3832 H Status, 383A H Mask]
Signal Name
Bits
Access
Default
Description
Clock island OFP_Rx2 lost clock
OFP_Rx2
OFP_Rx1
OFP_Tx2
OFP_Tx1
PH_Rx4
PH_Rx3
PH_Rx2
PH_Rx1
0
1
2
3
4
5
6
7
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
0
0
0
0
0
0
0
0
Clock island OFP_Rx1 lost clock
Clock island OFP_Tx2 lost clock
Clock island ACH_Tx1 lost clock
Clock island PH_Rx4 lost clock
Clock island PH_Rx3 lost clock
Clock island PH_Rx2 lost clock
Clock island PH_Rx1 lost clock
4.4: ClkStat4, ClkMask4 [3833 H Status, 383B H Mask]
Signal Name
Reserved
COMBUS4
COMBUS3
COMBUS2
COMBUS1
LTRC
Bits
0
Access
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Default
Description
0
0
0
0
0
0
0
0
Reserved
1
Clock island Telecom Bus 4 lost clock
Clock island Telecom Bus 3 lost clock
Clock island Telecom Bus 2 lost clock
Clock island Telecom Bus 1 lost clock
Clock island AIP lost clock
2
3
4
5
OFP_Rx4
OFP_Rx3
6
Clock island OFP_Rx4 lost clock
Clock island OFP_Rx3 lost clock
7
ssframer.01
8/27/99
Register Descriptions
Page 125 of 279
