Timer Interface B (TIMB)
then writing logic 0 to TOF has no effect. Therefore, a TOF interrupt request
cannot be lost due to inadvertent clearing of TOF. Reset clears the TOF bit.
Writing a logic 1 to TOF has no effect.
1 = TIMB counter has reached modulo value.
0 = TIMB counter has not reached modulo value.
TOIE — TIMB Overflow Interrupt Enable Bit
This read/write bit enables TIMB overflow interrupts when the TOF bit becomes
set. Reset clears the TOIE bit.
1 = TIMB overflow interrupts enabled
0 = TIMB overflow interrupts disabled
TSTOP — TIMB Stop Bit
This read/write bit stops the TIMB counter. Counting resumes when TSTOP is
cleared. Reset sets the TSTOP bit, stopping the TIMB counter until software
clears the TSTOP bit.
1 = TIMB counter stopped
0 = TIMB counter active
NOTE:
Do not set the TSTOP bit before entering wait mode if the TIMB is required to exit
wait mode. Also, when the TSTOP bit is set and the timer is configured for input
capture operation, input captures are inhibited until TSTOP is cleared.
TRST — TIMB Reset Bit
Setting this write-only bit resets the TIMB counter and the TIMB prescaler.
Setting TRST has no effect on any other registers. Counting resumes from
$0000. TRST is cleared automatically after the TIMB counter is reset and
always reads as logic 0. Reset clears the TRST bit.
1 = Prescaler and TIMB counter cleared
0 = No effect
NOTE:
Setting the TSTOP and TRST bits simultaneously stops the TIMB counter at a
value of $0000.
PS[2:0] — Prescaler Select Bits
These read/write bits select either the PTE0/TCLKB pin or one of the seven
prescaler outputs as the input to the TIMB counter as Table 17-1 shows. Reset
clears the PS[2:0] bits.
Data Sheet
266
MC68HC908MR32 • MC68HC908MR16 — Rev. 6.0
Timer Interface B (TIMB)
MOTOROLA
