Analog-to-Digital Converter
ATD Registers
16.4 ATD Registers
Control and data registers for the ATD modules are described below.
Both ATDs have identical control registers mapped in two blocks of 16
bytes.
Bit 7
0
6
0
5
0
4
0
3
0
2
0
1
0
Bit 0
0
RESET:
ATD0CTL0/ATD1CTL0 — Reserved
$0060/$01E0
Writes to this register will abort current conversion sequence.
READ: any time WRITE: any time.
Bit 7
0
6
0
5
0
4
0
3
0
2
0
1
0
Bit 0
0
RESET:
ATD0CTL1/ATD1CTL1 — Reserved
$0061/$01E1
WRITE: Write to this register has no meaning.
READ: Special Mode only.
MC68HC912DG128 — Rev 3.0
Technical Data
