Enhanced Capture Timer
BIT 7
BIt 7
Bit 7
0
6
6
6
0
5
5
5
0
4
4
4
0
3
3
3
0
2
2
2
0
1
1
1
0
BIT 0
Bit 0
Bit 0
0
$00A2
$00A3
PACN3 (hi)
PACN2 (lo)
RESET:
PACN3, PACN2 — Pulse Accumulators Count Registers
$00A2, $00A3
Read: any time
Write: any time
The two 8-bit pulse accumulators PAC3 and PAC2 are cascaded to form
the PACA 16-bit pulse accumulator. When PACA in enabled (PAEN=1
in PACTL, $A0) the PACN3 and PACN2 registers contents are
respectively the high and low byte of the PACA.
When PACN3 overflows from $FF to $00, the Interrupt flag PAOVF in
PAFLG ($A1) is set.
Full count register access should take place in one clock cycle. A
separate read/write for high byte and low byte will give a different result
than accessing them as a word.
BIT 7
BIt 7
Bit 7
0
6
6
6
0
5
5
5
0
4
4
4
0
3
3
3
0
2
2
2
0
1
1
1
0
BIT 0
Bit 0
Bit 0
0
$00A4
$00A5
PACN1 (hi)
PACN0 (lo)
RESET:
PACN1, PACN0 — Pulse Accumulators Count Registers
$00A4, $00A5
Read: any time
Write: any time
The two 8-bit pulse accumulators PAC1 and PAC0 are cascaded to form
the PACB 16-bit pulse accumulator. When PACB in enabled, (PBEN=1
